Automatic Triangle Nylon Corn Fiber Sachet Flower Tea Bag Packing Machine

The automatic triangle tea bag packing machine is designed to automatically form, fill, and seal triangular (pyramid) tea bags

  • Item No :

    JS-32S
  • Order(MOQ) :

    1
  • Payment :

    L/C, D/P, D/A, T/T, Cash.
  • Product Origin :

    Guangdong, China
  • Shipping Port :

    Guangzhou Port / Shenzhen Port
  • Weight :

    600KG

Automatic Triangle Nylon Corn Fiber Sachet Flower Tea Bag Packing Machine



Description

The machine is suitable for triangular inner bag and outer bag packaging of various small particle materials such as green tea, black tea, oolong tea, chrysanthemum tea, ginger tea, barley tea, mint tea, wolfberry tea, scented tea, herbal tea, etc.

tea bag



Specification

Packing Speed 20-50 bags/min (determined by materials and film)
Inner Bag Size Length: 40-80 mm (1.6-3.1") Width: 60-80 mm (2.4-3.1)
Outer Bag Size Length: 80-140 mm (3.1-5.5") Width: 70-120 mm (2.8-4.7)
Inner Bag Type Pyramid / Rectangular
Outer Bag Type Pillow bag /3 sides seal bag
Filling Range 1-10g
Air Comsumption
≥0.6Mpa, 0.4m³/min
Power
220V, 50/60Hz, 2.2 KW
Machine Size
3663(L)*1040(W)*2015(H)mm
Machine Weight
600KG



Main Feature

1. The machine can automatically finish materials loading, measuring, bag making, sealing, cutting, counting, finished product conveyor and other functions.

2. Intelligent PLC control, touch screen to set parameters, support for multiple languages, easy to understand.

3. The electronic scale is used to measure the material, and the measurement range is adjusted through the touch screen, and the measurement is fast and accurate.

4.  It can be used for flat bag packaging, triangle vertical packaging and other bag types through ultrasonic sealing and cutting.

5. The whole machine is made of SUS304 stainless steel, which is easy to clean and maintain, and has a longer service life.
