Automatic Pharmaceutical Paste Ointment Soft Tube Filling Sealing Machine

The automatic tube filling and sealing machine is used for soft tube, plastic tube and aluminium tube.

  • Item No :

    JS-09H
  • Order(MOQ) :

    1
  • Payment :

    L/C, D/P, D/A, T/T, Cash.
  • Product Origin :

    Guangdong, China
  • Shipping Port :

    Guangzhou Port / Shenzhen Port
  • Weight :

    2100KG

Automatic Pharmaceutical Paste Ointment Soft Tube Filling Sealing Machine



Description

The automatic tube filling and sealing machine is mainly used for soft plastic tube filling, sealing and coding process.

This machine is suitable for paste, skin cream, sunscreen, ointment, toothpaste, hair dye, shoe polish, AB glue, epoxy glue, etc.

tube filling machine



Specification

Production Capacity 40-60 cups/min
Filling Range 5-300ml (Can be customized)
Accuracy ±1%
Tube Diameter Φ15-Φ50mm
Tube Length 50-250mm
Water Consumption 3-6L/Min
Machine Size 1900(L)*800(W)*1600(H) mm
Voltage 220V/380V, 50/60HZ
Power 3Kw
Machine Weight 2100KG



Main Feature

1. The machine can automatically complete a series of processes such as tube feeding, metering, filling, sealing (tail folding), and finished product delivery.

2. The rotary 12 station design is adopted, which occupies a small area and is convenient for inspection and maintenance.

3. Use the intelligent touch screen to set the machine parameters, the operation is simple and convenient, and supports multiple languages.

4. The plexiglass cover is installed above the platform, which is convenient to observe the operation status of the machine and ensure the safety of production.

5. No tube no filling. The sealing temperature adopt (Leister hot air gun) insideheating for the tail of tube and cooling device for out of tube.
